Precast Coke Oven Door

Main Composition: Al2O3≥50%

Application: Industrial Furnaces and Equipment

Cold Crushing Strength: ≥35Mpa

Bulk Density: ≥2.1g/cm3

Refractoriness: ≥1700℃

Rupture Strength: ≥4Mpa

Capacity: 1000 MT per month

Package: Export wooden pallets and polyboard

Detail Leave Message Related Products

Introduction:
The surface of pre-cast refractory door is made of composite ceramic material. Pre-cast refractory is shaped by high frequency vibration. The unformed material has low porosity, high density and good uniformity. There is crystalline ceramic refractory adhere the pre-cast surface, which have high strength, good abrasion resistance and corrosion resistance. It has been reduced the physical damage during the operation and tar and other chemicals erosion to the refractory.

Features:
1.Simple structure and easy to install.
2.Good integrity and impermeability.
3.Longer working life than the traditional one.
4.Energy-saving and environment-friendly.

Application:
It's mainly used for the coke oven.

Technical Data:

Item	Pre-cast Coke Door
ω(Al₂O₃) / % ≥	50
ω(MgO) /% ≥	3
Apparent Porosity / % ≤	28
Bulk Density /g/cm³ ≥	2.1
Cold Crushing Strength / MPa ≥	35
Rupture Strength /MPa ≥	4
Thermal Conductivity /W/(m·K)1000℃ (Heating side) ≤	1.2
Thermal Shock Resistance(1100℃, water cooling) /cycle ≥	50

Comparison between new type and traditional type:

New type pre-cast coke oven door	Traditional oven door
Easy to install The fastening bolts have been inserted in the precast. The precast oven door is clamped to the door structure directly by that bolts.	The oven door installation is very complicated.
The oven door is more air impermeability. The new type oven door consists of 6 or 7 precast refractory glazing crystalline ceramic refractory surface. The whole oven door exist 5 or 6 joints.	Traditional oven door has more joints. The joints are easy to become bigger owing to long time mechanical operation. The air impermeability and insulating ability is worse. Heat loss, gas leakage and environment pollution are more serious.
Crystalline ceramic refractory glaze have high refractoriness, good bonding performance and malleability, good thermal shock resistance. During the operation, the glaze have good spalling resistance under rapid variation of temperature.	The raw materials of traditional door don’t have good mechanical strength and thermal shock resistance.
Long-life	Short-life
The maintenance times and costs are reduced, and the labor cost is decreased 70%.	Frequent repair and maintenance cost is high.
Energy-saving and environment-friendly Good heat insulation Less heat loss Improve the carbonation rate	Energy consumption and environment pollution Gas leakage Yellow smoke Heat dissipation
